Electrical issues
Hi guys, I’ve got a 2023 Lc300 it’s taken on some water and soaked the drivers side front floor. ive done the obvious and stripped the interior out, dried everything cleaned all the plugs checked for corrosion made sure no plugs have shorted out replaced the battery checked all fuses contact cleaned everything. Although I’m still having some issues, -drivers seat has no power to it -radio will display screen but won’t let me change anything touchscreen and steering wheel buttons don’t work -central locking plays up -shows warnings on dash I’ve spoken to Toyota all around Australia they have no idea I’ve spoken to a few electricians but no one wants a bar of it. I’m hoping someone here may be able to shed some light? Thanks.- water leak
- electrical
- (and 3 more)
-
2
P0303, rough idle, check VSC message.
Do you remember a Toyota ad [years ago] around the response "Bugger". Engine misfire causes include spark plug, ignition coil and fuel injector. When I checked my spark plugs as part of tracking down engine misfire, I found oil around a few of the spark plugs as a contributing factor. I also found a long 16mm swivel magnetic spark plug socket to be very handy. https://www.ebay.com.au/itm/196756153269?_skw=16mm+magnetic+spark+plug&itmmeta=01JHYWNWBVX4JXZ7C6WAZRFFDT&hash=item2dcf94a3b5:g:3BMAAOSws8pnHuBU&itmprp=enc%3AAQAJAAAA8HoV3kP08IDx%2BKZ9MfhVJKlqtUwJeOil2iRuVSCtyQOrqULI0EMgdE0a428A%2FFNAw%2FKD9hi2uQFLedafNJSbn%2Bp%2F8v7YkkPrwk%2FLCnBlEeH1XBEOuxRI3pEWxtouABez5uQ9KQf%2B4OJc%2FMxiKPMxxg0CRALap3ZJ4azh2jpPYIXWgexr9OtP53v8KvPIy6otDSy859N35OWs8Pnd4udqpCi7CFZVLebJRc%2BO0IgiqTpVM2tmErlndu1i8xDQP68j6wqsbSF%2BqS%2BXfvIa3AadyUrmg2d0gWwGnktyuIxKAM0HcQYqbvZm1G1Ztd%2FE1WeO6A%3D%3D|tkp%3ABk9SR5jG19yPZQ I have not yet replaced the spark plug seal gaskets but have them on my eBay watchlist. https://www.ebay.com.au/itm/196589707493 This video may be relevant. -
2
P0303, rough idle, check VSC message.
That video tells me bank 1, cylinder 3 is the rear, least accessible bank/cylinder. Good info, not so good news. -
2
-
2
P0303, rough idle, check VSC message.
Hello y'all. 2008 prodigy, 230Kkm. Recent service. Mildly rough idle, engine dash light on. Code reader shows P0303...cylinder 3 misfire. Then it had the "check vsc system" message. vsc light and engine dash warning lights are on. Daughter reports "the engine light flashes when I accelerate and it jolts a bit". Engine light doesn't flash at maintenance speed. fwiw, added 7 litres 85ron+ethanol to a 3/4 full 98ron tank. Did that in the hope it might clean something up. A 20km drive later, the engine light remains on (not flashing) and the vsc message is gone but the symbol still lit. Daughter reports "there is a clear improvement". Looking from the front of the motor, please confirm the position of cylinder 3. Adjacent to 1, so middle, but front or rear bank? I might pull the plug and coil if it's the front one. Cheers -
0
Cylinder head removal
1993 Toyota Corolla CSi Sedan I've had this car for about 10 years. During that time I've never really studied anything under the bonnet. I've been studying it very recently. I have to say I'm amazed at the plumbing and wiring attached to the engine. It makes me wonder what newer cars are like. I've only ever bought second-hand. Anyway, fully loaded, hot day, slow traffic, an up hill run (Brown Mountain, NSW), stop and go. The engine starts to make noises I'd rather it didn't make. Pull over let it cool. Eventually added some water but the engine didn't start. Leave it. Hitch a ride. Come back with another car and tow it. Annoyed with the thing and it sits idle for a few weeks. Back at, and it starts first go. I'm amazed. Drive it into a spot where I can work on it. A few months pass and I try to start it again. It wants to start - but no go. I get fed up trying. Then I'm shocked (but not surprised) to see, with the radiator full and the cap off that as I turn the engine over (it still won't start) huge amounts of water blowing out the radiator. It's a New Zealand Geyzer. And the engine isn't even running. At that point, I'm visualising a huge gap in the head gasket between one of the cylinders and the water jacket. The head has to come off. And I committed to doing that this weekend. I'm not enjoying this. Oh, it started as fun. I've removed heads before. Years ago. There's so much plumbing on this thing. I don't know what half of it is. Half the time I don't know if the plumbing are vacuum lines, water, or fuel. So many weird things on this engine. Werid to me, anyway. Plenty of pictures and notes taken, to help me put it back together again. I have to say that there are some aspects of this engine that make me feel that the designers should be shot, or at least strung up by the feet (like Django was in the movie) and beaten senseless. I removed the radiator - two bolts and it lifts out. Way to go. Good design. But most other things I found to be a pain. (For example, the thermostat housing seems to be attached to some other housing that has a water hose attached that runs along the back of the engine underneath the inlet manifold. I never knew it was there. It looks like it runs to the water pump. I don't know how anyone would gain access to that without removing the inlet manifold. What poor engine design.) So, here's the thing. If there's anyone out there who has experience with a 1993 model, give me a shout, and I'll put a few questions to you. -
2
1996 Caldina Fuel Pump Location
Walked away from the job last night came back this morning and found the location of the Fuel pump problem. Blocked return line and the OBD connection. Someone above must be looking over my shoulder Access to the fuel pump is via the left hand rear seat cushion (left it up) and the OBD connection is in the engine bay at on the left hand side wall. Pays to keep looking. -
-
2
1996 Caldina Fuel Pump Location
Can anyone describe where the OB2 Connection block is located on a right hand drive 1996 Caldina. I have looked under the drivers compartment side cover and through the fuse box area however I have not yet found the terminal box for the OBD monitor. -
10
04 Estima cruise control speed limited?
Hi guys how it's going? We have a 2004 Estima and we're trying to fit a cruise control. Unfortunately there is no factory plug and so we are using the factory connector for the assumed audio control and and jacking off the Top Left 1 and 3 pins. Does anyone know the correct pins for the Cruise Control? Photo below
-
