no tail or dash lights

[vjcrose]

I have been through the fuses and they all seem ok however I have no dash lights or tail lights - the head lights still work.

any suggestions are most appreicated - which fuse? and thing else I have missed???

[v8toy]

hi

[vjcrose]

hi

you could help here v8toy! oh thats right you all ready tried

[v8toy]

yeah i know i know but im a bike mechanic/trailer builder/welder/what ever else needs doin but as far as auto lecky stuff goes changin fuses is about it lol

[ELEGNT]

moisture in the fuses did that to old my Excel, its looks fine but thats wat it was in my case.

good luck!

sorry i had to post this pic because i need to steal the link for my signature he he :D

[vjcrose]

there are 4 fuse boxes :o on the acr30 2 in the engine bay and one behind the drivers kick panel and another behind the passengers kick panel and up to the left of the main glove box.

I only knew of three when i found the fourth it had 2 blown fuses - all fixed now... :)

[Rolla Boy]

Your tail light fuse is blown...

[drgtr]

Sorry for being up an old thread. But just wanted to say thank you. I bought some LED tail lights today but it blew the fuse. This is my 2001 v6 Estima.

I knew of the fuse panel in the engine bay x2 and the driver side kick panel.

I didnt know about the passenger kick panel as I didnt look high  enough until I read this post.

I was panicking when all fuses were intact. Was going to call the mobile mechanic

It took out the tail lights, Dash lights and number plate lights and fog lights.

So I swapped with a working fuse and voila.



Awesome post.
